3/4" Sq. Drv. Heavy Duty Impact Wrench Product Specifications
230V
900W
Impact Wrench
Heavy Duty Impact Tool
High-grade Alloy Steel and Composite Housing
Manual Trigger
Black & Silver
Yes
4.2 kg
900W
290 x 90 x 220 mm
Reversible Action, Ergonomic Grip, High Torque Output
85 dB(A)
Twin Hammer Mechanism
50 Hz
3/4 Inch Square Drive
Heavy Duty Industrial Usage, Automotive Repair, Construction
Bolt Tightening and Loosening
Pneumatic (Compressed Air)
2 Speed
Product Description
3/4" Sq. Drv. Heavy Duty Impact Wrench
Maximum Torque Nm/(ft-lb)
1,650 / (1,217)
Working Torque Range Nm/(ft-lb)
0 - 1,320 / (0 - 974)
Bolt Cap mm/(in.)
24 / (15/16)
Free Speed rpm
(F)6,000 (R)6,500
Weight kg/(lb)
3.25 / (7.7)
Over Length mm/(in.)
218 / (8.58)
Noise Level dBA/(power)
101 / (114)
Vibration m/s2
9.1
Avg.Air Consumption CFM
8.0
Air Inlet Size in.
1/4
Hose Size mm/(in.)
13 / (1/2)
Clutch Type
Twin Hammer
Unmatched Power for Heavy Duty Applications
Engineered for high-impact industrial tasks, this impact wrench boasts a formidable 1350 Nm max torque and supports bolt sizes up to M24. Its robust design ensures reliability and durability, even when tackling the most challenging tightening and loosening operations in workshops, garages, or construction sites.
Efficient Operation & Ergonomic Handling
Designed with user comfort in mind, the pistol grip and composite housing reduce fatigue during extended use. An efficient twin hammer mechanism increases operational longevity, while the variable speed and reverse functions provide full control for precise work on every application.
Versatile and Complete Tool Kit
This heavy-duty impact wrench is suitable for a multitude of sectors including automotive, manufacturing, and infrastructure. Included accessoriessuch as a nipple, oil pot, and hex keyhelp ensure smooth maintenance and enhance the longevity of the tool, making it a reliable choice for professionals.
FAQs of 3/4" Sq. Drv. Heavy Duty Impact Wrench:
Q: How do I properly use the 3/4" Heavy Duty Impact Wrench for tightening and loosening bolts?
A: To use the impact wrench, connect it to a compressor delivering 6.2 bar (90 psi) via the included nipple, ensuring the air line matches the 1/2 inch inlet. Select the appropriate socket for bolts up to M24, set the desired rotation (forward for tightening, reverse for loosening), and adjust speed. Engage the manual trigger to operate, allowing the twin hammer mechanism to apply torque as required.
Q: What maintenance steps are recommended for this pneumatic impact wrench?
A: Routine maintenance includes lubricating with the supplied oil pot, checking connections and hoses for leaks, and keeping the tool clean. Inspect the composite housing and moving parts regularly. Replace worn components as necessary using the hex key. This routine ensures optimal performance and longevity.
Q: When should I use this impact wrench instead of a standard wrench?
A: Utilize the heavy-duty impact wrench when working with stubborn, heavily torqued, or large-size bolts (up to M24), particularly in industrial, automotive, or construction settings where manual tools may not provide adequate force or speed. Its high torque output saves time and reduces physical effort.
Q: Where is the exhaust located and how does it benefit operation?
A: The impact wrench features a bottom exhaust, which directs discharged air away from the operator and work area. This design minimizes air disturbance and provides a cleaner, more comfortable environment during use.
Q: What are the benefits of the twin hammer mechanism in this impact wrench?
A: The twin hammer mechanism delivers consistent high torque while distributing impact forces evenly, resulting in smoother operation, faster bolt removal or tightening, and increased tool durability.
Q: What safety precautions should I observe when operating this tool?
A: Always wear appropriate personal protective equipment, including eye and ear protection, given the noise level of 85 dB(A). Ensure secure connections, check for air leaks, and keep hands away from moving parts. Only use the wrench within its rated specifications to prevent damage or injury.
