Product Description
Ga.Brad Nailers/Coil Nailers
16 - 18 Ga. Brad Nailers
- Molding & Decorative Trim
- Up hoistered & Trim Panels
- Picture Frame Assembly
- Cabinet Work
- Door & Window Casing
- Rattan
- Interior & External
- Furniture Trim.
Coil Nailers
- Sheathing
- Decking
- Sub flooring
- Create, Pallet
- Box assembly
- Magnesium Alloy Housing reduce weight
- Lost-wax casting precision in size, Special mterial for durability
- 360o adjustable exhaust port
- Ergonomical design for continuous operation
- High volume magazine holds up to 300 nails
- Adjustable depth of drive for precision nailing
- No mr rubber tip device.
Model
| Fastener Compatible Model
| Fastener
| Toll Specifications
|
Head Dia.
(mm (inch)
| Shank Dia.
mm (inch)
| Length
(mm)
| Shank Type
| Collated
| Pressure
| Load Capacity
| Dimensions
(H x W x L) (mm)
| Weight
(kg)
|
C-57P
| Max CN55
Bostitch N57C
| 5.0 ~ 5.7
(0.197" ~ 0.224")
| 2.1 ~ 2.3
(0.083" ~ 0.090")
| 25 ~ 57
| Smooth
Screw
Ring
| Wire
Plastic Sheet
| 5 ~ 7.5kg/cm2
75 ~ 110 psi
| 200 ~ 300 PCS
| 310 x 130 x 300
| 2.2
|
C-75PA
| Max CN-710
Bostitch N70CB
| 6.0 ~ 7.0
(0.236" ~ 0.275")
| 2.5 ~ 2.9
(0.090" ~ 0.114")
| 45 ~ 75
45 ~ 70
45 ~ 70
| Smooth
Screw
Ring
| 200 ~ 300 PCS
| 340 x 130 x 310
| 3.6
|
C-75PB
| 7.0
(0.275")
| 2.9 ~ 3.3
(0.114" ~ 0.129")
|
C-90PA
| Max CN85
Bostitch N86C | 7.0
(0.275")
| 2.9 ~ 3.8
(0.114" ~ 0.129")
| 50 ~ 90
50 ~ 83
50 ~ 83
| Smooth
Screw
Ring
| 150 ~ 300 PCS
| 365 x 130 x 310
| 3.7
|
C-90PB
|
| 7.0 ~ 7.5
(0.275" ~ 0.295")
| 3.3 ~ 3.8
(0.275" ~ 0.150")
|
C-100
| Bostitch N100C
| 6.0 ~ 7.5
(0.236" ~ 0.295")
| 2.9 ~ 3.8
(0.114" ~ 0.150")
| 50 ~ 100
50 ~ 90
50 ~ 90
| Smooth
Screw
Ring
| Wire
| 150 ~ 300 PCS
| 385 x 135 x 360
| 5.0
|
Model
| Fastener Compatible Model
| Fastener
| Tool Specifications
|
Nail Type
| Head Dia.
(mm)
| Shank Thickness
mm (inch)
| Shank Width
mm (inch)
| Length
(mm)
| Gauge
B.W.G.
| Pressure
| Load Capacity
| Dimensions
(H x W x L) (mm)
|
F18/35
| Bostitch BT35
| Brad
| 1.9
| 1.0 (0.04")
| 1.25 (0.05")
| 10 ~ 35
| 18
| 4 ~ 7kg/cm2
60 ~ 100 psi
| 100 PCS
| 210 x 59 x 260
|
F18/57
| Senco Finis Pro 25
| Brad
| 1.9
| 1.0 (0.04")
| 1.25 (0.05") | 15 ~ 57
| 18
| 4 ~ 7kg/cm2
60 ~ 100 psi
| 100 PCS | 260 x 59 x 250
|
F16/50
| Bea SK400
| Brad
| 2.8
| 1.4 (0.055")
| 1.6 (0.06")
| 20 ~ 50
| 16
| 4 ~ 7kg/cm2
60 ~ 100 psi | 100 PCS | 270 x 77 x 310
|
