Product Description
Push Start Screw Driver:
| Model No. | Free Speed | Weight | O.A.L. | Diameter | Noise Level | Air hose base Air Inlet 6kg/cm3 | Air Consumption | Torque Range | Standard Deviation | Fastening Capacity |
| r.p.m. | g | mm | mm | ±2dBA | mm | m3/min | Kgf-cm | % | Machine Srew Dia. | Tapping Screw Dia. |
| T10PB | 1000 | 430 | 180 | 29 | 7.4 | 5.0 | 0.2 | 0.5 - 2 | ±3 | M1.0-M2.2 | M1.1-M1.7 |
| T30PB | 1800 | 430 | 180 | 29 | 74 | 6.35 | 0.28 | 2 - 16 | ±3 | M2.2-M4.2 | M1.6-M3.2 |
| T35PB | 2200 | 430 | 180 | 29 | 7.4 | 6.35 | 0.28 | 3 - 20 | ±3 | M2.4-M4.5 | M2.0-M3.5 |
| T40PB | 1000 | 430 | 180 | 29 | 74 | 6.35 | 0.28 | 5 - 30 | ±3 | M2.8-M5.0 | M2.2-M4.0 |
| T45PB | 800 | 430 | 180 | 29 | 74 | 8.0 | 0.3 | 8 - 40 | ±3 | M3.6-M5.7 | M2.7-M4.4 |
| T48PB | 1800 | 770 | 215 | 37 | 7.8 | 9.5 | 0.55 | 7 - 50 | ±3 | M2.9-M6.0 | M2.6-M4.7 |
| T50PB | 1400 | 770 | 215 | 37 | 78 | 9.5 | 0.55 | 7 - 55 | ±3 | M2.9-M6.0 | M2.6-M4.9 |
| T55PB | 1000 | 770 | 215 | 37 | 78 | 9.5 | 0.55 | 7 - 65 | ±3 | M2.9-M6.4 | M2.6-M5.4 |
| T60PB | 550 | 770 | 215 | 37 | 78 | 9.5 | 0.55 | 15 - 95 | ±3 | M4.1-M7.0 | M3.3-M6.0 |
| T65PB | 300 | 810 | 215 | 37 | 7.8 | 9.5 | 0.55 | 30 - 180 | ±3 | M5.0-M9.0 | M4.0-M7.0 |
T68PB
| 250
| 1100
| 215
| 39
| 78
| 10
| 0.60
| 50-280
| +-3
| M6-M11
| M4.9-M8.7
|
| Model No. | Free Speed | Weight | O.A.L. | Diameter | Noise Level | Air hose base Air Inlet 6kg/cm3 | Air Consumption | Torque Range | Vibration Level | Standard Deviation | Fastening Capacity |
| r.p.m. | gm | mm | mm | ±2dBA | mm | m3/min | Kgf-cm | ms² | % | Machine Srew Dia. | Tapping Screw Dia. |
| R41BBP | 1000 | 640 | 180 | 33 | 7.4 | 6.35 | 0.28 | 05 - 35 | <2.5 | ±3 | M2.8-M5.2 | M2.2-M4.2 |
| R50BBP | 1400 | 980 | 215 | 39 | 7.8 | 9.5 | 0.55 | 10 - 60 | <2.5 | ±3 | M3.6-M6.3 | M2.8-M5.0 |
| R55BBP | 1000 | 980 | 215 | 39 | 7.8 | 9.5 | 0.55 | 12 - 75 | <2.5 | ±3 | M3.8-M6.6 | M3.0-M5.4 |
| R60BBP | 550 | 980 | 215 | 39 | 7.8 | 9.5 | 0.55 | 30 - 110 | <2.5 | ±3 | M5.0-M7.8 | M4.0-M6.2 |
| R65BBP | 300 | 1100 | 215 | 39 | 7.8 | 9.5 | 0.55 | 30 - 180 | <2.5 | ±3 | M5.0-M9.5 | M4.4-M7.5 |
| Model No. | Free Speed | Weight | O.A.L. | Diameter | Noise Level | Air hose base Air Inlet 6kg/cm3 | Air Consumption | Torque Range | Vibration Level | Standard Deviation | Fastening Capacity |
| r.p.m. | g | mm | mm | ±2dBA | mm | m3/min | Kgf-cm | ms² | % | Machine Srew Dia. | Tapping Screw Dia. |
| T50AB | 1400 | 1100 | 335 | 37 | 78 | 9.5 | 0.55 | 7 - 50 | <2.5 | ±3 | M2.9-M6.0 | M2.6-M4.9 |
| T55AB | 1000 | 1100 | 335 | 37 | 78 | 9.5 | 0.55 | 7 - 65 | <2.5 | ±3 | M2.9-M6.4 | M2.6-M5.4 |
| T60AB | 550 | 1100 | 335 | 37 | 78 | 9.5 | 0.55 | 15 - 95 | <2.5 | ±3 | M4.1-M7.0 | M3.3-M6.0 |
| T65AB | 300 | 1100 | 335 | 37 | 78 | 9.5 | 0.55 | 30 - 180 | <2.5 | ±3 | M5.1-M9.0 | M4.4-M7.0 |
| Model No. | Free Speed | Weight | O.A.L. | Height
| Dia. | Fastening Capacity | Min Air hose bore | Air Consumption | Torque range Soft Joint | Noise Level |
| r.p.m. | kg | mm | mm | mm | mm² | mm | m³/min | Nm | ±2dBA |
| R48BPN | 1,700 | 0.87 | 165 | 154 | 39 | 3 - 6 | 8.0 | 0.55 | 1.5 - 6.0 | 78 |
| R58BPN | 750 | 0.87 | 165 | 154 | 39 | 3 - 7 | 8.0 | 0.55 | 1.5 - 9.0 | 78 |
| Model No. | Free Speed | Weight | O.A.L. | Diameter | Fastening Capacity | Min Air hose bore | Air Consumption | Torque range Soft Joint | Noise Level |
| r.p.m. | g | mm | mm | mm² | mm | m³/min | Nm | ±2dBA |
| R39LBN | 1,800 | 0.6 | 140 | 35 | 2.5 - 5 | 6.35 | 0.28 | 0.5 - 4.0 | 72 |
| R48LBN | 1,700 | 0.84 | 195 | 43 | 3 - 6 | 8.0 | 0.55 | 0.6 - 6.0 | 77 |
| R58LBN | 750 | 0.84 | 195 | 43 | 3 - 7 | 8.0 | 0.55 | 0.6 - 9.0 | 77 |
Torque ARM
- Reduce operator fatigue and increase productivity with the MIJY LAND Torque ARM Ergonomic tool support system series.
- Telescoping reach from end of forearm allows easy adjustment in 1 inch increments
- Resistance can be set to suit individual operator preference
- Reduce operator fatigue
- Provide consistency and accuracy for repetitive assembly tasks
- Heavy duty construction
- For use with pneumatic and electric tools
| Air Cylinder Series
| Air Cylinder Series
|
Model No.
| STD-15110-AC
| PARA-15110-AC
|
Description
| Standard
| Parallel
|
Reach
| 4-33"
| 4-33" |
Capacity
| 0-6.8 kg"
| 0-6.8 kg" |
Maximum Torque
| 125 kgf-cm
| 125 kgf-cm |
M & L Air Screwdriver has following features
Accuracy: M & L Provide patent clutch with +- 3% deviation of torque. Assure the best quality
Economic: Wide - ranging torque with many patent and longer life cycle ofmotor.
Delicacy: Combination of art, ergonomics and mechanical design.
Technology: Special Mechanical structure and patent motor give you low noise, low vibration and high accuracy.
Straight Handle:Lever start shut-off Screw Driver.
Straight Handle: Push start shut-off Screw Driver.
