Product Description
F.R.L Combinations
Specification
Description / Type
| FRL504
| FRL804
|
Port Size (PT, NPT)
| 1/2"
| 1/2"
|
Filter Element
| 5u
| 20u
|
ADJ. Pressure Range (kgf/cm)
| 0.5~10.2 lgf/cm | 0.5~10.2 lgf/cm |
| Max Service Pressure (kgf/cm) | 10.25 kgf/cm | 15 kgf/cm |
Max flow (L/Min)
| 2100
| 2200
|
Operating Temp Range
| 5C~60C | 5C~60C |
Drain Capacity
| 55 ml
| 80 ml
|
Oil Capacity
| 80ml
| 125ml
|
Recommendable Lubricants
| ISO VG-32
| ISO VG-32
|
Type of Constitution unit
| Filter/Regulator
| FR504
| F.R 804
|
Lubricator
| L504
| L804
|
Material: Steel
20SHA
| 5/16" (Hose)
| 20PHA
| 5/16" (Hose) |
30SHA
| 3/8" (Hose) | 30PHA
| 3/8" (Hose) |
40SHA
| 1/2" (Hose) | 40PHA
| 1/2" (Hose) |
20SFA
| 1/4" (PT)
| 20PFA
| 1/4" (PT) |
30SFA
| 3/8"(PT)
| 30PFA
| 3/8"(PT) |
40SFA
| 1/2"(PT)
| 40PFA
| 1/2"(PT) |
20SMA
| 1/4"(PT)
| 20PMA
| 1/4"(PT) |
30SMA
| 3/8"(PT)
| 30PMA
| 3/8"(PT) |
40SMA
| 1/2"(PT)
| 40PMA
| 1/2"(PT) |
20SPA
| 5X8MM
| 20PPA
| 5X8MM |
30SPA
| 6.5X10MM
| 30PPA
| 6.5X10MM |
40SPA
| 8X12MM
| 40PPA
| 8X12MM |
Specification
Material
| Body: Aluminum
|
Working Pressure
| 10~15 kgf/cm
|
Mamimum Pressure
| 15~20 kgf/cm |
Temp. Range
| -20C~+80C |
Size
| 1/4" (20 type)
|
Size
| 1/4" (20 type)
| 3/8" (30 type)
| 1/2" (40 type)
|
Features - One way automatic shut-off value in the socket.
- Wide variety provides best choice according to application.
- Hardened important parts are extremely wear resistant and durable.
- Chrome plated steel body for anti corrosion gives long erm, stable functioning.
- Tested 100,000 times, coupler connection is accurate and reliable.
Applications - Pneumatic tools
- Air piping
- Air pressure equipment
- Water piping
