Product Description

Air Rivetors / Nutsest Tools

Hydraulic Riveter

Technical Specifications

Model No.	Blind Rivet Capacity (Inch)	Traction Power (Kgs)	Stroke Length (mm)	Air Consumption (cfm)	Weight (kg)	Air Inlet (inch)
R-15	3/16", 5/32", 1/8", 3/32"	720	14	0.03	1.5	1/4"
R-16V	3/16", 5/32", 1/8"	900	17	0.03	1.5	1/4"
R-13 BV	3/16", 5/32", 1/8"	820	18	0.03	1.4	1/4"
R-6100V	3/16", 5/32", 1/8", 3/32"	1000	16	0.04	1.80	1/4"
R-6103V	1/4", 3/16", 5/32", 1/8"	1700	23	0.05	2.4	1/4"

Model No	Chisel Shank (In)	Piston Stroke (mm)	BPM	Overall Length (mm)	Air Consumption (cfm)	Weight (Kgs)	Air Inlet
H-10 (R)	0.401	41	4,500	133	5	1.5	1/4"
H-20 (R)	0.401	66	3,000	178	5.5	2.0	1/4"
H-30 (R)	0.401	92	2,200	216	6	2.2	1/4"
RH-204	0.401	73	2,200	185	6	1.30	1/4"

Model No	Capacity (mm)	Free Speed (rpm)	Weight (kg)	Air Consumption (cfm)	Air Hose Size	Air Intel
PS-1001	M-8	350	1.3	5	3/8	1/4"

Model No	Capacity (mm)	Free Speed (rpm)	Weight (kg)	Air Consumption (cfm)	Air Hose Size	Air Intel
OP-PS-06	M3-M6	600	1.2	2	3/8	1/4"
OP-PS-10	M6-M10	450	1.8	2	3/8	1/4"
OP-PS-12	M6-M12	100	1.92	2	3/8	1/4"

Model No.	Overall Length Approx.	Net weight Approx.	Recommended Air pressure		Hose Size		Air Consumption
Model No.	mm	kgf.	psi	bar	in	mm	m³/min
RY-221	270	1.55	90	6.2	1/4"	6.3	0.48
